Jackhammer Air Hose Assemblies

Product name:25mm Rubber air hose
Inside Dia.:25.4mm
Outside Dia.:36mm
Working Pressure:20kg/cm²
Material:Rubber

Key words：

Rock Drill Hose

Related Products

Message

Product Details

Description

Jackhammer Air Hose Assemblies, or air compressor hoses, are utilized to connect pneumatic tools to their compressed air source or manifold. We can custom configure and offer a variety of standard assemblies in a variety of colors, diameters, and pressure ratings. We offer a heavy-grade wrapped cover hose,These durable contractors hose assemblies are designed for rigorous outdoor use.
Our compressed air hose assemblies are made from domestic EPDM/PDM rubber which is an elastomer that is known for good all weather flexibility, ozone resistance, and durability. EPDM hose can handle a light oil mist such air supplied by a compressor with an inline oiler installed. For oily environments, a nitrile rubber hose may be more suitable.The EPDM rubber also provides flexibility in cold temperatures for this industrial grade jackhammer hose. Made with Red PDM Rubber to protect from elements like sunlight, ozone and alcohol to name a few. 50 ft length allows you to reach jobs far from your air compressor. Coils up easily when the job is done. We only offer the best quality products and this is no exception with this high performing jackhammer air hose

Performance

jackhammer hose that is made to perform and to last

Applications

It is used for Jackhammer.

Specification

Item Code	I.D		O.D	W.P		B.P		L
	inch	mm	mm	bar	psi	bar	psi	m	ft
JAH-019	3/4"	19.1	29	20	300	60	900	100	330
JAH-025	1"	25.4	36	20	300	60	900	100	330

HENGLONG workshop and Process of manufacturing

Packing and shipping

Factory

Customer visit

Production

QUALITY INSPECTION PROCESS

Product quality is one of the core links in the development and growth of Yanggu Henglong Engineering Co., Ltd. Our company has strict internal and external inspection processes to ensure the quality of our products. Our inspection process for our products is as follows.
